China Hg5003 Non Destructive Testing Equipment Portable Vibration Calibrator Sine Waveform wholesale

Hg5003 Non Destructive Testing Equipment Portable Vibration Calibrator Sine Waveform

Name: Hg5003 Non Destructive Testing Equipment Portable Vibration Calibrator Sine Waveform
Brand: HUATEC
Price: 1 USD

Ask Latest Price

Brand Name :HUATEC

Model Number :HG5003

Certification :ISO CE

Place of Origin :CHINA

MOQ :1

Payment Terms :T/T, Western Union

Supply Ability :500

Packaging Details :in carton

Accuracy :5%

Acceleration Amplitude(RMS) :9.81m/s2（1g）±3%

Output Waveform :Sine Waveform

Waveform Distortion :5%

Maximum Load :120Gram

Working Temperature :0-55º C

Contact Now

Add to Cart

View Product Description

HG5003 Vibration Calibratorcan be used to calibrate small vibration transducers and also vibration measuring instruments

HG5003 Vibration Calibrator

General Description

HG5003 Vibration Calibrator can be used to calibrate small vibration transducers and also vibration measuring instruments and vibration monitoring systems quickly. Standard sine signals with fixed frequency 159.2Hz and fixed amplitude is generated from the calibrator.

HG5003 Vibration Calibrator combines sine signal generator, power amplifier, standard transducer and shaker in one and features a smaller volume, high accuracy and easy operation. It can be used either in laboratory or on site.

Specifications

Accuracy: 5%
Acceleration Amplitude(RMS):9.81m/s²(1g)±3%
Velocity Amplitude (RMS):9.81mm/s±3%
Displacement Amplitude (RMS):9.81µm±3%
Automatic power off time: 50seconds.
Working temperature: 0-55 ^oC
Size:Φ52×160mm
Weight: 600 gram (with batteries)
Tapped hole for sensor installation: M5 x 30mm

Operation

Fix M5 screw, accelerometer on the shaker table of the calibrator

Press the only switch at the calibrator to start the vibration.

Compare the reading of your vibration meter before the shaker power off after 50sec.

The LED will turn from GREEN to ORANGE when battery low. It means you need to recharge the battery for 15 hours.
